NTPsec

ntp-sdr

Report generated: Tue Nov 19 23:00:03 2019 UTC
Start Time: Mon Nov 18 23:00:01 2019 UTC
End Time: Tue Nov 19 23:00:01 2019 UTC
Report Period: 1.0 days

Local Clock Time/Frequency Offsets

local offset plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Time Offset-776.000-501.000-348.0002.000316.000 439.000706.000664.000940.000201.481-2.726ns-4.253 10.91
Local Clock Frequency Offset-4.763-4.762-4.760-4.745-4.705 -4.703-4.7010.0560.0590.0187-4.739ppm-1.646e+074.186e+09

The time and frequency offsets between the ntpd calculated time and the local system clock. Showing frequency offset (red, in parts per million, scale on right) and the time offset (blue, in μs, scale on left). Quick changes in time offset will lead to larger frequency offsets.

These are fields 3 (time) and 4 (frequency) from the loopstats log file.



Local RMS Time Jitter

local jitter plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Time Jitter66.000140.000163.000234.000328.000 371.000469.000165.000231.00050.718238.207ns 62.07 278.9

The RMS Jitter of the local clock offset. In other words, how fast the local clock offset is changing.

Lower is better. An ideal system would be a horizontal line at 0μs.

RMS jitter is field 5 in the loopstats log file.



Local RMS Frequency Jitter

local stability plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Frequency Jitter32.00056.00065.00092.000139.000 183.000227.00074.000127.00023.72796.11010e-12 38.84 164.6

The RMS Frequency Jitter (aka wander) of the local clock's frequency. In other words, how fast the local clock changes frequency.

Lower is better. An ideal clock would be a horizontal line at 0ppm.

RMS Frequency Jitter is field 6 in the loopstats log file.



Local Clock Time Offset Histogram

local offset histogram plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Offset-776.000-501.000-348.0002.000316.000 439.000706.000664.000940.000201.481-2.726ns-4.253 10.91

The clock offsets of the local clock as a histogram.

The Local Clock Offset is field 3 from the loopstats log file.



Peer Offsets

peer offsets plot

The offset of all refclocks, peers and servers. This can be useful to see if offset changes are happening in a single clock or all clocks together.

Clock Offset is field 5 in the peerstats log file.



Peer Offset 192.36.143.150

peer offset 192.36.143.150 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Offset 192.36.143.150-225.555-212.912-206.485-197.581-186.279 -182.410-178.65020.20630.5026.208-197.267µs-3.53e+041.16e+06

The offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Peer Offset 192.36.143.151

peer offset 192.36.143.151 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Offset 192.36.143.151-230.155-215.308-209.499-201.747-192.494 -187.693-182.63917.00527.6155.525-201.363µs-5.262e+041.974e+06

The offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Peer Offset 192.36.143.234

peer offset 192.36.143.234 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Offset 192.36.143.234-227.777-211.342-198.409-178.487-145.871 -137.484-128.60452.53873.85815.145-176.854µs -20752.677e+04

The offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Peer Offset 194.58.202.148

peer offset 194.58.202.148 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Offset 194.58.202.148-11.349-10.795-8.280-1.7595.164 7.7358.60813.44418.5304.021-1.850µs-7.293 18.93

The offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Peer Offset 194.58.202.20

peer offset 194.58.202.20 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Offset 194.58.202.20-13.983-7.542-1.6113.63410.098 14.73518.77011.70922.2773.9413.750µs-0.2873 5.867

The offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Peer Offset 194.58.205.148

peer offset 194.58.205.148 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Offset 194.58.205.148-24.225-21.563-16.297-6.4445.513 8.90411.05621.81030.4675.986-6.037µs-13.98 42.89

The offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Peer Offset SHM(0)

peer offset SHM(0) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Offset SHM(0)-659.794-521.128-439.759-352.225-288.290 12.37528.380151.469533.50367.926-351.242ms-251.1 1636

The offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Peer Offset SHM(2)

peer offset SHM(2) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Offset SHM(2)-777.000-502.000-349.0003.000317.000 440.000707.000666.000942.000202.247-2.715ns-4.252 10.89

The offset of a peer or server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the remote. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN peer 80µs; 90% ranges for WAN servers may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Peer Jitters

peer jitters plot

The RMS Jitter of all refclocks, peers and servers. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Peer Jitter 192.36.143.150

peer jitter 192.36.143.150 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Jitter 192.36.143.1504.0895.1157.14515.10844.308 808.927809.59737.163803.81293.08530.468µs 5.112 42.46

The RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Peer Jitter 192.36.143.151

peer jitter 192.36.143.151 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Jitter 192.36.143.1512.8195.2536.31613.35630.283 198.675206.74923.967193.42224.70017.575µs 5.92 43.54

The RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Peer Jitter 192.36.143.234

peer jitter 192.36.143.234 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Jitter 192.36.143.23421.20924.50128.94248.60870.323 85.461209.90941.38160.96016.00249.208µs 18.84 111.4

The RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Peer Jitter 194.58.202.148

peer jitter 194.58.202.148 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Jitter 194.58.202.1482.3014.9316.61513.40123.711 48.149196.04917.09643.21814.92115.427µs 8.455 89.49

The RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Peer Jitter 194.58.202.20

peer jitter 194.58.202.20 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Jitter 194.58.202.204.2765.3926.42113.51623.952 37.35940.03117.53131.9675.71114.258µs 8.949 30.52

The RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Peer Jitter 194.58.205.148

peer jitter 194.58.205.148 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Jitter 194.58.205.1480.0040.0050.0080.0180.035 1.4422.6360.0271.4370.2340.045ms 7.163 79.3

The RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Peer Jitter SHM(0)

peer jitter SHM(0) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Jitter SHM(0)2.7465.5418.09025.640196.457 387.636538.464188.367382.09568.35849.125ms 2.521 12.85

The RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Peer Jitter SHM(2)

peer jitter SHM(2) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Peer Jitter SHM(2)36.00090.000117.000217.000411.000 520.000875.000294.000430.00091.051234.802ns 9.742 32.57

The RMS Jitter of a remote peer or server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Summary


Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset-4.763-4.762-4.760-4.745-4.705 -4.703-4.7010.0560.0590.0187-4.739ppm-1.646e+074.186e+09
Local Clock Time Offset-776.000-501.000-348.0002.000316.000 439.000706.000664.000940.000201.481-2.726ns-4.253 10.91
Local RMS Frequency Jitter32.00056.00065.00092.000139.000 183.000227.00074.000127.00023.72796.11010e-12 38.84 164.6
Local RMS Time Jitter66.000140.000163.000234.000328.000 371.000469.000165.000231.00050.718238.207ns 62.07 278.9
Peer Jitter 192.36.143.1504.0895.1157.14515.10844.308 808.927809.59737.163803.81293.08530.468µs 5.112 42.46
Peer Jitter 192.36.143.1512.8195.2536.31613.35630.283 198.675206.74923.967193.42224.70017.575µs 5.92 43.54
Peer Jitter 192.36.143.23421.20924.50128.94248.60870.323 85.461209.90941.38160.96016.00249.208µs 18.84 111.4
Peer Jitter 194.58.202.1482.3014.9316.61513.40123.711 48.149196.04917.09643.21814.92115.427µs 8.455 89.49
Peer Jitter 194.58.202.204.2765.3926.42113.51623.952 37.35940.03117.53131.9675.71114.258µs 8.949 30.52
Peer Jitter 194.58.205.1480.0040.0050.0080.0180.035 1.4422.6360.0271.4370.2340.045ms 7.163 79.3
Peer Jitter SHM(0)2.7465.5418.09025.640196.457 387.636538.464188.367382.09568.35849.125ms 2.521 12.85
Peer Jitter SHM(2)36.00090.000117.000217.000411.000 520.000875.000294.000430.00091.051234.802ns 9.742 32.57
Peer Offset 192.36.143.150-225.555-212.912-206.485-197.581-186.279 -182.410-178.65020.20630.5026.208-197.267µs-3.53e+041.16e+06
Peer Offset 192.36.143.151-230.155-215.308-209.499-201.747-192.494 -187.693-182.63917.00527.6155.525-201.363µs-5.262e+041.974e+06
Peer Offset 192.36.143.234-227.777-211.342-198.409-178.487-145.871 -137.484-128.60452.53873.85815.145-176.854µs -20752.677e+04
Peer Offset 194.58.202.148-11.349-10.795-8.280-1.7595.164 7.7358.60813.44418.5304.021-1.850µs-7.293 18.93
Peer Offset 194.58.202.20-13.983-7.542-1.6113.63410.098 14.73518.77011.70922.2773.9413.750µs-0.2873 5.867
Peer Offset 194.58.205.148-24.225-21.563-16.297-6.4445.513 8.90411.05621.81030.4675.986-6.037µs-13.98 42.89
Peer Offset SHM(0)-659.794-521.128-439.759-352.225-288.290 12.37528.380151.469533.50367.926-351.242ms-251.1 1636
Peer Offset SHM(2)-777.000-502.000-349.0003.000317.000 440.000707.000666.000942.000202.247-2.715ns-4.252 10.89
Summary as CSV file

Glossary:

frequency offset:
The difference between the ntpd calculated frequency and the local system clock frequency (usually in parts per million, ppm)
jitter, dispersion:
The short term change in a value. NTP measures Local Time Jitter, Refclock Jitter, and Peer Jitter in seconds. Local Frequency Jitter is in ppm or ppb.
kurtosis, Kurt:
The kurtosis of a random variable X is the fourth standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of kurtosis. A normal distribution has a kurtosis of three. NIST describes a kurtosis over three as "heavy tailed" and one under three as "light tailed".
ms, millisecond:
One thousandth of a second = 0.001 seconds, 1e-3 seconds
mu, mean:
The arithmetic mean: the sum of all the values divided by the number of values. The formula for mu is: "mu = (∑xi) / N". Where xi denotes the data points and N is the number of data points.
ns, nanosecond:
One billionth of a second, also one thousandth of a microsecond, 0.000000001 seconds and 1e-9 seconds.
percentile:
The value below which a given percentage of values fall.
ppb, parts per billion:
Ratio between two values. These following are all the same: 1 ppb, one in one billion, 1/1,000,000,000, 0.000,000,001, 1e-9 and 0.000,000,1%
ppm, parts per million:
Ratio between two values. These following are all the same: 1 ppm, one in one million, 1/1,000,000, 0.000,001, and 0.000,1%
‰, parts per thousand:
Ratio between two values. These following are all the same: 1 ‰. one in one thousand, 1/1,000, 0.001, and 0.1%
refclock:
Reference clock, a local GPS module or other local source of time.
remote clock:
Any clock reached over the network, LAN or WAN. Also called a peer or server.
time offset:
The difference between the ntpd calculated time and the local system clock's time. Also called phase offset.
σ, sigma:
Sigma denotes the standard deviation (SD) and is centered on the arithmetic mean of the data set. The SD is simply the square root of the variance of the data set. Two sigma is simply twice the standard deviation. Three sigma is three times sigma. Smaller is better.
The formula for sigma is: "σ = √[ ∑(xi-mu)^2 / N ]". Where xi denotes the data points and N is the number of data points.
skewness, Skew:
The skewness of a random variable X is the third standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of skewness. Wikipedia describes it best: "The qualitative interpretation of the skew is complicated and unintuitive."
A normal distribution has a skewness of zero.
upstream clock:
Any remote clock or reference clock used as a source of time.
µs, us, microsecond:
One millionth of a second, also one thousandth of a millisecond, 0.000,001 seconds, and 1e-6 seconds.



This page autogenerated by ntpviz, part of the NTPsec project
html 5    Valid CSS!
